Magnetostrictive displacement sensor:
Introduction:
The magnetostrictive displacement sensor, base on the magnetostrictive position sensing principle, contactless operation ensures product long service life, better adaptability to industrial environment; absolute output, restart don't need from zero; High accuracy,high stability, the best durability and repeatability. Variety of output signals which include the current, voltage, SSI, Modbus, Profibus etc., can meet any industrial applications such as petroleum, chemical industry, steel and iron, port, machinery, food and so on. It is the best
choice for high accuracy displacement control.
Features
1) high precision 0.05% FS
2) durable, hermetically sealed design
3) anti-interference ability, lower working current
4) non-contact measurement, no wearing
5) zero point adjustable scope to full range
6) support two places measurement at the same time
Application:
1) oil cylinder and air cylinder, hydraulic cylinder position detection
2) oil tank, medicine bottle reservoir etc level measurement
3)valve, gate open degree testing
4) mechanical equipment mobile location feedback
5)injection molding machine template orientation and monitoring
parameters:
|
measurement
|
position、speed（absolute velocity），can measuring1～2 positions
|
|
|
range
|
|
50 mm～8000mm
|
|
Adjusted range to zero
|
100%F.S
|
|
output
|
current
|
4～20mA,max resistor load 600Ω
|
|
voltage
|
0～10VDC 0～5VDC,min load＞5KΩ
|
|
precision
|
resolution
|
use 16Bit D/A transform，0.0015%F.S（min1μm）
|
|
nonlinear
|
<±0.015%F.S（min±50μm）
|
|
repeatability
|
<±0.002%F.S（min±3μm）
|
|
hysteresis
|
<0.002%F.S.
|
|
Temperature coefficient
|
<0.007%F.S./℃
|
|
Refresh
|
range<0.5ms/m
|
|
|
|
|
|
power
|
+24VDC±10%
|
|
current
|
<50m A
|
|
Operating temp.
|
-40～+85℃
|
|
Storage temperature
|
-40～+100℃
|
Analog output
|
Wiring
|
Pins description
|
|
Aviation plugs
|
Cable colors
|
Single magnet
|
Single magnet with reverse line
|
Single magnet with debugging serial port
|
Double point output
|
|
|
Pin1
|
red
|
+24VDC power supply
|
|
Pin2
|
white
|
GND1
|
|
Pin3
|
blue
|
GND1
|
|
Pin4
|
green
|
NC
|
NC
|
TXD
|
GND2
|
|
Pin5
|
brown
|
NC
|
Reverse line
|
RXD
|
GND2
|
|
Pin6
|
Bare wire
|
Shielding wire
|
|
Pin7
|
black
|
Power supply
|
